Shagun BWP

Shagun BWP

As the name suggests Shagun Marine Plywood is water proof. Exposure to alternate soaking and drying as well as the currents and forces of the waves have little impact on the plywood because of its high densifiedness, specially formulated zero emission resin, modern technological knowhow, skilled workers, updated R&D. Above all, the seasoned and solid hardwood combination of gurjan species with double calibration, super OCTA technology, SOPs and specific structural composition makes it ideal for marine applications.

As per BIS:710:2010
a-% SQ 0.10%
Edge Straightness C-MC 0.12%
Glue Stear Strength (dry) 7.09%
Addition Plies Excellent
Glue Stear Strength (wet) AVG-1230N
Addition of Plies Pass standard
Micological Test 1180N
Tensile Strength
Along the Grain 56.10N/M M2
Across the Grain 35.20N/M M2
Sum of two direction 91.40N/M M2
MOR (Dry State)
Along the grain 52.40N/MM2
Across the Grain 33.10N/MM2
MOR (Wet State)
Along the grain 27.90N/MM2
Across the Grain 17.60N/MM2
MOE (Dry State)
Along the grain 7650N/MM2
Across the Grain 4330N/MM2
MOE (Wet State)
Along the grain 3810N/MM2
Across the Grain 2140N/MM2
Retention of Preservative 13.20kg/M3
